Nouveau Servo brushless SRT 1/8e BH9022 HV Agrandir l'image

Servo brushless SRT 1/8e BH9022 HV

bh9022

Neuf

95,00€ TTC

En achetant ce produit vous pouvez gagner jusqu'à 9 points de fidélité. Votre panier totalisera 9 points de fidélité pouvant être transformé(s) en un bon de réduction de 0,90€.


  • Type: Digital
    Bearing: Dual
    Motor Type: Brushless
    Gear Type: Metal
    Gear Material: Titanium & Alu
    control system: pulse width control
    working frequence: 1520μs / 330hz
    operating voltage: dc6.0-8.4v
    operating temperature range: -10 to + 60 degree
    operating speed (6.0v): 0.085 sec/60 degrees at no load
    operating speed (7.4v): 0.065 sec/60 degrees at no load
    operating speed (8.4v): 0.060 sec/60 degrees at no load
    stall torque (6.0v): 18.0kg.cm (249.9 oz/in)
    stall torque (7.4v): 20.0kg.cm (277.7 oz/in)
    stall torque (8.4v): 22.0kg.cm (305.5 oz/in)
    potentiometer drive: direct drive
    dimensions: 40x20x38.0 mm /1.57x0.79x1.49 in
    weight: 70.0g (2.47 oz)
    connector wire length: jr 250 mm
